Time & Tide for Dials < 4mm

Stock Code:
QTIDE.14
RRP:
$55.00
Your Price:
$55.00
Stock Level:
36 Available
Make an Enquiry

Details

Description

"Takane" Quartz

Part Number : QTIDE.14

Description : Quartz Time & Tide Movement 15 mm
(Max. Dial Thickness 4 mm)

Size : 73 mm High x 55 mm Wide x 25 mm Thick
Weight : 60 Grams
Material : ABS Plastic Case

Features : Time ( Hours, Minutes, Seconds )
Also Drives Tide Hand
Hand shaft is 14 mm long total
Max dial thickness to trap is 4 mm or less
Dial hole should be a minimum of 11 mm

Shaft Stepped at 6mm,8 mm,12 mm (measured from Base Plate)

Uses :
Euroshaft Design Specifications
Hour hand hole bush is 5mm dia
Minute hand hole is slotted 4mm dia slotted is 3mm

Hand nut thread is metric 4mm with pitch of 0.5mm
Locking Nut Thread is metric 10mm with pitch of 0.75mm

Suits : These Parts
E122.0000 Battery ( "AA" or LR6 )
HQ. Hands

Notes : Hands purchased separately. See HQ. Range of Time Hands & HQ.171.RED (Tide Hand)

See : Other Quartz
